Fish meat mining machine Products:

      Device is the use of meat mining machine rollers and belt squeezing movement of fish collection principle, the device is the most important three parts, the first, sheet metal equipment, because it is in direct contact with food, fish and pure color, a certain plate 304 stainless steel sheet to be used, if the carbon steel material is very susceptible to rust to rust debris fell into the fish flesh pollution, second, equipment belt, the belt is particularly important in the whole device, if the belt is not strong it will not cause fish collection Clean waste of raw materials, the loss is very large, third, roller mesh, mesh smaller the clean and more intensive collection. This is like we use a mesh sieve sand reason, the smaller the screen hole sieve out of the sand will be finer. Some buyers in order when you purchase must clearly identify.

Fish meat mining machine works:

     Fish meat mining machine is equipped mining meat bucket and squeeze the meat with the rubber band, the mutual use of the press rolling motion mining meat barrels and drive the rubber band will squeeze into the mining flesh barrel of fish, but the fish skin, fish bones left in the flesh barrel outside, it sends by the scraper outside the machine.

Part of the structure and uses

1, drum scraper: Fish for separating from the inner cylinder from the inner wall of the drum is scraped off

2, meat, mining drum: for collecting fish

3, the automatic adjustment device: Flesh for automatically adjusting the pressure correction, the gap reset action

4, fixed blade wheel: for fixing the outer drum scraper

5, the outer drum scraper: used to scrape off the separated bones and skin of fish

6. Flesh belt: for transporting fish and meat mining machine with rollers squeeze the formation of strong fish isolated

7, the gap adjusting handle: adjust the gap Flesh and meat mining belt between the rollers

8, power lines: 150, 200 220v, 380v can be used, need to use more than 300 380v

9, the power switch: start the machine for controlling and stopping

10, belt tension adjustment: Flesh for adjusting the belt tension

Fish meat mining machine parameters:

Model 150 200 300 350

Size (mm) 850 * 680 * 900 900 * 880 * 950 1150 * 870 * 1060 1300 * 1000 * 1050

Equipment Material SUS304 SUS304 SUS304 SUS304

Yield (kg / h) 180 280 360 15000

Power (kw) 2.2 2.2 2.2 7.5

Belt Thickness (mm) 20 20 20 20

Belt Length (mm) 1195 1450 1450 2500

Roller diameter (mm) 162 219 219 300

Roller thickness (mm) 2.7 2.7 2.7 4 / 4.5 / 5 / 6mm

Machine weight (kg) 220 260 320 750

Equipment price (yuan) 8,000,120,001,400,060,000
