product description:

Fish Flesh fish meat mining machine price large fish meat mining machine manufacturers versatile fish meat mining machine can not only collect fish bones and fish bones isolated skin, but also in fish can leave the sub-fascia, make fish more clean It does not affect the taste of post-processing.

Many customers worried that the device will not be used to buy back, the device is only good after commissioning the factory, so that turned on the electricity can be used, but if the fish are collected sample sizes, or need to be adjusted, the adjustment very simple way, the device has two adjustable handle, a fish is to adjust the belt tension, one is to adjust the gap between the drum and the belt, the belt tightening, the smaller the gap between the roller and the belt, the more fish out of the collection clean, handle up regulation is loose, adjust down tight, due to the nutrient-rich fish, eat flavored, and the human body has a strong health care function, so people generally love to eat fish. But the wide variety of fish, different fish have different health care functions. Fish collected at the time of the acquisition out of the surimi-like, can be directly used in deep processing of fish. Fish fishbone separator, machine peeled shrimp, fish meat mining machine, crab meat mining machine, factory direct fish separator also known as fish meat mining machine, take the machine surimi, shrimp separator, go fish bone machine loach flesh, go fish bone machine by pressing the principle of fish and fish bone aliquots to leave before the fish harvest fish meat paste required to head and internal organs. Fish separator ordinary and stainless steel material, ordinary material separator fish in two models, namely 150, 200, 300, 350.

Fish meat mining machine for fish, freshwater fishes. Fish into segments, taken directly fish meat. You can fish in the fish and fish bones, skin, tendons fish were separated to improve the utilization of raw materials, the purpose of saving labor costs and improve the economic value of low-value fish.

working principle:

Fish meat mining machine is equipped mining meat bucket and squeeze the meat with the rubber band, the mutual use of the press rolling motion mining meat barrels and drive the rubber band will squeeze into the mining flesh barrel of fish, but the fish skin, fish bones left in the flesh barrel outside, it sends by the scraper outside the machine.

Part of the structure and uses

1, drum scraper: Fish for separating from the inner cylinder from the inner wall of the drum is scraped off

2, meat, mining drum: for collecting fish

3, the automatic adjustment device: Flesh for automatically adjusting the pressure correction, the gap reset action

4, fixed blade wheel: for fixing the outer drum scraper

5, the outer drum scraper: used to scrape off the separated bones and skin of fish

6. Flesh belt: for transporting fish and meat mining machine with rollers squeeze the formation of strong fish isolated

7, the gap adjusting handle: adjust the gap Flesh and meat mining belt between the rollers

8, power lines: 150, 200 220v, 380v can be used, need to use more than 300 380v

9, the power switch: start the machine for controlling and stopping

10, belt tension adjustment: Flesh for adjusting the belt tension

Device parameters

Model 150 200 300 350

Size (mm) 850 * 680 * 900 900 * 880 * 950 1150 * 870 * 1060 1300 * 1000 * 1050

Equipment Material SUS304 SUS304 SUS304 SUS304

Yield (kg / h) 180 280 360 15000

Power (kw) 2.2 2.2 2.2 7.5

Belt Thickness (mm) 20 20 20 20

Belt Length (mm) 1195 1450 1450 2500

Roller diameter (mm) 162 219 219 300

Roller thickness (mm) 2.7 2.7 2.7 4 / 4.5 / 5 / 6mm

Machine weight (kg) 220 260 320 750

Equipment price (yuan) 8,000,120,001,400,060,000
